DS2400Q QAM Analyzer Operation Manual
DEVISER 44 DS2400Q
3.7 Channel Scanning
DS2400Q support channel scanning function in
order to test the flatness and amplitude of cable
TV system quickly.
Press to return to main menu interface and
press or to select the SCAN icon, and
then press to enter Channel Scanning
function as Figure 3-7-1，
The scanning graph of current user plan is
displayed on the screen, a slider in red color
shows the current scanning channel.
Figure 3-7-1
