DS2400Q QAM Analyzer Operation Manual
DEVISER 104 DS2400Q
5. Power Supply
5.1 Battery
DS2400Q uses built-in 12.6V 1.5AH Li-Polymer
battery and works over 5 when fully charged.
When the voltage of the battery drops below 11V,
the battery icon flashes in screen. Once the
voltage of the battery is lower than 10.6V, the
instrument will shut down automatically. The
charge time is about 3 hours.
NOTE：
1. The meter can be only charged by the
charger provided together with DS2400Q.
2. It is suggested to close the instrument when
charging.
3. Low temperature may reduce the capability
of the battery, but the battery will not be
damaged.
