DS2400Q QAM Analyzer Operation Manual
DEVISER 57 DS2400Q
NOTE: DS2400Q checks the analog channel only
in Limit Test mode.
3.10.1 Test Results List
After the limit test scanning, the general test
results of cable system will be listed. The test
items are consist of minimum video level,
maximum video level, maximum delta video level,
minimum V/A, maximum V/A and maximum
ADJ channels. Refer to figure 3-10-2.
Figure 3-10-2
