DS2400Q QAM Analyzer Operation Manual
DEVISER 45 DS2400Q
Green color represents video level of analogue
channels.
Yellow color represents audio level of analogue
channels.
Blue color represents power of digital channels.
The scan function also display the channel
number of scanning start channel and end
channel.
3.7.1 Soft Keys Operation
TAB ( ): Press this button can modify the
cursor location. Then the parameter which
highlighted on the yellow color background can be
modified by or .
MARK: In figure 3-7-1, press the or
and the marker with red color will move left or right.
And the test result of channel at the position of
marker will be displayed on the bottom of the
screen.
