DS2400Q QAM Analyzer Operation Manual
DEVISER 38 DS2400Q
3.6 Tilt/Level List Measurement
Tilt/Level list test is the effective solution to check
the flatness and splitter’s gain of cable system,
DS2400Q can get levels of 12 channels and
observe the measurement result and graph easily.
Press to return to main menu interface, and
press or and choose Tilt icon, then
press to enter Tilt/Level List measurement.
Please select at least four channels to do tilt test,
otherwise it will pop-up one dialog box as Figure
3-6-1.
Figure 3-6-1
