DS2400Q QAM Analyzer Operation Manual
DEVISER 61 DS2400Q
3.11 Return Path Spectrum
Press to return to main menu interface and
press or to select the R-PATH icon,
and then press to enter R-PATH function, as
Figure 3-11-1.
Figure3-11-1
In the interface of the R-PATH function, the default
parameter set is Start frequency: 5MHz, Stop
frequency: 65MHz, Reference: 40dBuV, Scale:
5dB/div, Demodulation mode: peak mode.
In this function， to view the detailed soft key
instruction, please refer to 3.8.
