Devolo dLAN 1200+ WiFi ac User Manual

12 Introduction
devolo dLAN 1200+ WiFi ac
쎲 The LED lights up white if the
dLAN 1200+ WiFi ac is ready to operate and a
dLAN connection exists.
쎲 The LED flashes white quickly at regular inter-
vals if the encryption process (pairing) is being
performed in the dLAN network.
쎲 The LED flashes white at irregular intervals if
the dLAN 1200+ WiFi ac is in PowerSave
mode.
쎲 The LED flashes red at regular intervals if the
transmission rate of the dLAN 1200+ WiFi ac is
not in the optimum range. For information on
improving the transmission rate, refer to Chapter
6.1 Bandwidth optimization.
WiFi Move Technology
WiFi Move Technology is a function for synchronising
the WiFi settings of all WiFi adapters. Activate the syn-
chronisation either using the functions on the configu-
ration interface (see Chapter 5.3.6 WiFi Move) or at
the touch of a button on the adapter.
햲 First press the encryption button with the home
icon (for about 1 second) on an existing
dLAN 1200+ WiFi ac that has the entire WiFi
configuration which is to be transferred to all
other dLAN 1200+ WiFi ac adapters. Then,
within 2 minutes, press each encryption button
on the new dLAN 1200+ WiFi ac devices (for
about 1second).
햳 The WiFi adapters are now continuously con-
nected to each other and, from now on, share
changes to the WiFi configuration with each
other automatically.
2.3.2 WiFi button
The WiFi button controls the following WiFi
functions:
WiFi On/Off:
쎲 In the factory default settings, the WiFi set-
ting is already enabled and the WiFi encryption is
set to WPA2. The default WiFi key for the initial
installation of the dLAN 1200+ WiFi ac is the
adapter's WiFi key. You will find the unique key on
the label on the back of the housing.
Fig. 3

Devolo dLAN 1200+ WiFi ac Specifications

General

Ethernet LAN	Yes
Wi-Fi standards	802.11g, Wi-Fi 5 (802.11ac), 802.11b, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Security algorithms	WPA2, 128-bit AES, WPS-PBC, WPA, WPS-PIN
Networking standards	IEEE 802.3u, IEEE 802.11a, IEEE 802.11n, IEEE 802.3x, IEEE 802.11ac, IEEE 802.11b, IEEE 802.3, IEEE 802.3az, IEEE 802.11g, IEEE 802.3ab
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	2
Maximum data transfer rate	1200 Mbit/s
Maximum operating distance	400 m
Ethernet LAN interface type	Gigabit Ethernet
Certification	CE Class B (EU, CH, NO)
Product color	White
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	196-250 V
AC input frequency	50 Hz
Cables included	LAN (RJ-45)
Quantity per pack	1 pc(s)
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	40 mm
Width	152 mm
Height	76 mm
Package depth	187 mm
Package width	115 mm
Package height	80 mm
Package weight	120 g
