Devolo dLAN 1200+ WiFi ac User Manual

Network configuration 43
devolo dLAN 1200+ WiFi ac
Before the networking procedure,
note the security IDs of all dLAN
adapters. This unique identifier of
each dLAN device is located on the
label on the back of the housing. It
consists of 4 x 4 letters separated by
dashes (e.g. ANJR-KMOR-KSHT-
QRUV). Ensure that all dLAN adapters
are connected to the mains supply
and computers or other network
components as appropriate.
Ethernet status
The status (red = not connected, green = connected)
and connection speed of the network jacks are dis-
played here.
Firmware version
The firmware version is displayed here. Clicking or tap-
ping Firmware update takes you directly to the cor-
responding menu. For more information about the
firmware update, refer to Chapter 5.6.4 System.
Access password
For security you can set a login password for access to
the configuration interface. The colour of the lock icon
tells you whether an individualised login password or
no password at all is set (green = individualised pass-
word, red = no password). Clicking or tapping Set ac-
cess password takes you directly to the
corresponding menu. More information about creating
an access password can be found in Chapter 5.6.4
System.
Network configuration
Network settings such as the IP address and subnet
mask of the dLAN 1200+ WiFi ac are displayed here.
Clicking or tapping Configure network takes you di-
rectly to the network settings. For more information,
refer to Chapter 5.6.3 Network settings.
5.5 Device configuration
You can find everything about your dLAN
in the Device configuration area. Click
or tap the respective icon to go the corre-
sponding area.
5.5.1 dLAN settings
In a dLAN network, all connected components must
use the same password. The dLAN password can be
defined in the devolo Cockpit App or the
devolo Cockpit program by using the encryption
button with the home icon or at this location in the
configuration interface. You can configure the pass-
word for the entire network.

Devolo dLAN 1200+ WiFi ac Specifications

General

Ethernet LAN	Yes
Wi-Fi standards	802.11g, Wi-Fi 5 (802.11ac), 802.11b, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Security algorithms	WPA2, 128-bit AES, WPS-PBC, WPA, WPS-PIN
Networking standards	IEEE 802.3u, IEEE 802.11a, IEEE 802.11n, IEEE 802.3x, IEEE 802.11ac, IEEE 802.11b, IEEE 802.3, IEEE 802.3az, IEEE 802.11g, IEEE 802.3ab
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	2
Maximum data transfer rate	1200 Mbit/s
Maximum operating distance	400 m
Ethernet LAN interface type	Gigabit Ethernet
Certification	CE Class B (EU, CH, NO)
Product color	White
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	196-250 V
AC input frequency	50 Hz
Cables included	LAN (RJ-45)
Quantity per pack	1 pc(s)
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	40 mm
Width	152 mm
Height	76 mm
Package depth	187 mm
Package width	115 mm
Package height	80 mm
Package weight	120 g
