42 Network configuration
devolo dLAN 1200+ WiFi ac
쎲 If WLAN configuration  Access Point  No
encryption is selected in advance, WPA2 is set
automatically. The newly generated password is
displayed under WiFi configuration  Access
Point in the Key field.
쎲 If WLAN configuration  Access Point 
WPA/WPA2 is selected in advance, this setting
remains with the previously assigned password.
5.4 Status overview
In the Status overview area, you get
general information about all connected
dLAN, WiFi and LAN devices.
Information about the dLAN 1200+ WiFi ac is also dis-
played in this menu on the left next to the status of the
connected WiFi, dLAN and LAN devices. On the right
in the menu you will find the corresponding link to go
directly to the menu.
WLAN status
Here you can see whether the WiFi function of your
dLAN 1200+ WiFi ac is switched on or off, as well as
whether encryption is used and which frequency band
has been configured.
Clicking or tapping Access Point takes you directly to
the WiFi settings. More information about WiFi
network security can be found in Chapter 5.3.1
Access point.
Clicking or tapping Configure guest account takes
you directly to the corresponding menu. More
information about configuring the guest account can
be found in Chapter 5.3.3 Guest account.
Click or tap WiFi monitor to display all of the known
WiFi devices. If there is an Internet connection and a
time server has been found, each WiFi device known
since the last system start is displayed along with its
name, MAC and IP address, the last login date and, if
possible, the speed.
dLAN status
The colour of the lock icon tells you whether an individ-
ualised dLAN password or the default password is set
(green = individualised password, red = default pass-
word). Click or tap dLAN devices to display all of the
connected dLAN devices. For more information about
this, refer to Chapters 5.5.2 dLAN devices and
5.5.2 dLAN devices.
Clicking or tapping Configure dLAN takes you to the
dLAN settings. For more information, refer to Chap-
ter 5.5.1 dLAN settings.

Devolo dLAN 1200+ WiFi ac Specifications

General

Ethernet LAN	Yes
Wi-Fi standards	802.11g, Wi-Fi 5 (802.11ac), 802.11b, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Security algorithms	WPA2, 128-bit AES, WPS-PBC, WPA, WPS-PIN
Networking standards	IEEE 802.3u, IEEE 802.11a, IEEE 802.11n, IEEE 802.3x, IEEE 802.11ac, IEEE 802.11b, IEEE 802.3, IEEE 802.3az, IEEE 802.11g, IEEE 802.3ab
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	2
Maximum data transfer rate	1200 Mbit/s
Maximum operating distance	400 m
Ethernet LAN interface type	Gigabit Ethernet
Certification	CE Class B (EU, CH, NO)
Product color	White
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	196-250 V
AC input frequency	50 Hz
Cables included	LAN (RJ-45)
Quantity per pack	1 pc(s)
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	40 mm
Width	152 mm
Height	76 mm
Package depth	187 mm
Package width	115 mm
Package height	80 mm
Package weight	120 g
