Devolo dLAN 1200+ WiFi ac User Manual

28 devolo cockpit
devolo dLAN 1200+ WiFi ac
The bar graph reflects the connection quali-
ty. The data rate is displayed in Mbps. Tap-
ping on a respective adapter allows you to
read the transfer rate for another device from
the selected adapter's point of view.
Tapping on the gear/arrow brings you to the
configuration interface for the
dLAN 1200+ WiFi ac. For more detailed in-
formation on the interface refer to Chapter 6
Network configuration.
Tapping on the recycle bin removes the con-
nected adapters.
4.1.2 Settings menu
Tapping on the two gears brings you to the set-
tings menu for the respective adapter.
Here you have the option of assigning a unique new
name for yourself and to reset the respective device to
the factory default settings. In addition, you can
learn about device information such as the firmware
version in use and the individual MAC address.
4.1.3 Menu on the bottom edge of the
screen
The functions of the menu on the bottom edge of the
screen are self-explanatory and can be operated intui-
tively. Depending on which submenu you are in, the
following functions appear:
쎲 Start: devolo Cockpit start menu
쎲 You can always use the Refresh option to display
the current status of devices that have been found
(if this hasn't happened automatically).
쎲 During the initial installation of the adapter, select
the Add adapter option.
쎲 The Troubleshooting guide contains additional
installation aids.
쎲 Security: Tapping on the key icon allows you to
change the dLAN password for either the entire
dLAN network or just for the respective adapter or
to reset it to the factory defaults.
The factory default password is
HomePlugAV. For security reasons,
we recommend setting an
individualised dLAN password.
4.2 devolo Cockpit software
devolo Cockpit is a monitoring and encryption
program that detects all reachable dLAN devices in
your home network and combines them in a secure
network. Due to its logical graphic design, the

Devolo dLAN 1200+ WiFi ac Specifications

General

Ethernet LAN	Yes
Wi-Fi standards	802.11g, Wi-Fi 5 (802.11ac), 802.11b, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Security algorithms	WPA2, 128-bit AES, WPS-PBC, WPA, WPS-PIN
Networking standards	IEEE 802.3u, IEEE 802.11a, IEEE 802.11n, IEEE 802.3x, IEEE 802.11ac, IEEE 802.11b, IEEE 802.3, IEEE 802.3az, IEEE 802.11g, IEEE 802.3ab
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	2
Maximum data transfer rate	1200 Mbit/s
Maximum operating distance	400 m
Ethernet LAN interface type	Gigabit Ethernet
Certification	CE Class B (EU, CH, NO)
Product color	White
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	196-250 V
AC input frequency	50 Hz
Cables included	LAN (RJ-45)
Quantity per pack	1 pc(s)
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	40 mm
Width	152 mm
Height	76 mm
Package depth	187 mm
Package width	115 mm
Package height	80 mm
Package weight	120 g
