Devolo dLAN 1200+ WiFi ac User Manual

32 devolo cockpit
devolo dLAN 1200+ WiFi ac
The factory default password is
HomePlugAV. Assigning a specific
password to a single adapter will
exclude it from the remaining dLAN
network.
If devolo Cockpit is called up again later after a suc-
cessful initial installation, for example to integrate a
new adapter into a network, the application remem-
bers the devices that were entered earlier. Enter the
new device as described in the Adding an adapter
section. The current network password is assigned
automatically to the newly added device.

Devolo dLAN 1200+ WiFi ac Specifications

General

Ethernet LAN	Yes
Wi-Fi standards	802.11g, Wi-Fi 5 (802.11ac), 802.11b, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Security algorithms	WPA2, 128-bit AES, WPS-PBC, WPA, WPS-PIN
Networking standards	IEEE 802.3u, IEEE 802.11a, IEEE 802.11n, IEEE 802.3x, IEEE 802.11ac, IEEE 802.11b, IEEE 802.3, IEEE 802.3az, IEEE 802.11g, IEEE 802.3ab
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	2
Maximum data transfer rate	1200 Mbit/s
Maximum operating distance	400 m
Ethernet LAN interface type	Gigabit Ethernet
Certification	CE Class B (EU, CH, NO)
Product color	White
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	196-250 V
AC input frequency	50 Hz
Cables included	LAN (RJ-45)
Quantity per pack	1 pc(s)
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	40 mm
Width	152 mm
Height	76 mm
Package depth	187 mm
Package width	115 mm
Package height	80 mm
Package weight	120 g
