Devolo GIGAGATE User Manual

10 Introduction
devolo GigaGate
a transfer rate of up to 1300 Mbps thanks to the larger
channel bandwidth and improved data transmission
technology.
2.2 The devolo GigaGate
The devolo GigaGate Base is equipped with:
쎲 One LED that indicates the devolo GigaGate Base
operation
쎲 One LED that indicates the status of the connec-
tion between the Base and Satellite
The LED status display can be disa-
bled on the GigaGate configuration
interface (see Chapter 4.3.2 Basic set-
tings).
쎲 One gigabit network jack (1000 Mbps)
쎲 Four internal WiFi antennas that use 4x4 Quan-
tenna technology (point-to-point connection),
쎲 Fold-down feet
쎲
Four holes (on each side) for wall mounting
쎲 One power socket for the included mains adapter.
The devolo GigaGate Satellite is equipped with:
쎲 One LED that indicates the devolo GigaGate Sat-
ellite operation
쎲 an LED that displays the status of the connection
between the Satellite and Base
쎲 One WiFi button with LED status display which
enables WiFi devices to connect using WPS
쎲 One gigabit network jack (1000 Mbps)
쎲 Four Fast Ethernet ports (100 Mbps)
쎲 Four internal WiFi antennas that rely on 4x4
Quantenna technology (point-to-point connec-
tion) as well as two internal WiFi antennas, which
can be used to establish a WiFi connection to
other network devices
Fig. 2: devolo GigaGate Base and Satellite

Devolo GIGAGATE Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Modulation	OFDM
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1733 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
Product type	Tabletop router
Product color	Black
LED indicators	LAN, Link, Power, WLAN
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Memory card slot(s)	-
Ethernet LAN (RJ-45) ports	5
Output voltage	12 V
Power source type	AC
Power consumption (typical)	9.1 W
Package depth	243 mm
Package width	190 mm
Package height	110 mm
Package weight	1200 g
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Security algorithms	WPA, WPA2
Cables included	AC, LAN (RJ-45)

Weight and Dimensions

Depth	140 mm
Width	150 mm
Height	30 mm
