16 Introduction
devolo GigaGate
쎲 To change the configuration of the
devolo GigaGate back to the factory defaults,
press the Reset button for more than 10 sec-
onds. Keep in mind that all settings that have
already been configured will be lost!
You can use a pointed object (such as a paper
clip) to press the Reset button.
2.2.4 WiFi antennas
The four internal WiFi antennas on the
devolo GigaGate Base have 4x4 Quantenna technolo-
gy. A total of four parallel point-to-point connections
with a speed of up to 1300 Mbps are set up here for
the devolo GigaGate Satellite using the less interfer-
ence-prone 5 GHz frequency band.
The devolo GigaGate Satellite also has two internal
antennas which can be used to establish a WiFi con-
nection to other network devices.

Devolo GIGAGATE Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Modulation	OFDM
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1733 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
Product type	Tabletop router
Product color	Black
LED indicators	LAN, Link, Power, WLAN
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Memory card slot(s)	-
Ethernet LAN (RJ-45) ports	5
Output voltage	12 V
Power source type	AC
Power consumption (typical)	9.1 W
Package depth	243 mm
Package width	190 mm
Package height	110 mm
Package weight	1200 g
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Security algorithms	WPA, WPA2
Cables included	AC, LAN (RJ-45)

Weight and Dimensions

Depth	140 mm
Width	150 mm
Height	30 mm
