Devolo GIGAGATE User Manual

Annex 37
devolo GigaGate
5 Annex
5.1 Frequency range and
transmitting power
Technical specifications in the 5 GHz frequency range
Technical specifications in the 2.4-GHz frequency range
Frequency range 5 GHz
IEEE standard 802.11 a/h
802.11 n
802.11 ac
Indoor frequency
range
5150 – 5350 MHz
Indoor & outdoor
frequency range
5150 – 5725 MHz
(802.11 a/h, n)
5150 – 5350 MHz /
5470 – 5725 MHz
(802.11 ac)
Channel bandwidth 20 MHz (802.11 a/h)
20, 40 MHz (802.11 n)
20 MHz, 40 MHz, 80 MHz, 160
MHz (802.11 ac)
Max. indoor transmis-
sion power (EIRP)
200 mW (channel 36 – 64) /
23 dBm
Max. transmitting
power
1,000 mW (channel 100 – 140)
/ 30 dBm
Frequency range 2.4 GHz
IEEE standard 802.11 b
802.11 g
802.11 n
Indoor frequency
range
–
Indoor & outdoor
frequency range
2399.5 – 2484.5 MHz
Channel bandwidth 20 MHz (802.11 b/g)
20, 40 MHz (802.11 n)
Max. indoor transmis-
sion power (EIRP)
100 mW / 20 dBm
Max. transmitting
power
100 mW / 20 dBm

Devolo GIGAGATE Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Modulation	OFDM
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1733 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
Product type	Tabletop router
Product color	Black
LED indicators	LAN, Link, Power, WLAN
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Memory card slot(s)	-
Ethernet LAN (RJ-45) ports	5
Output voltage	12 V
Power source type	AC
Power consumption (typical)	9.1 W
Package depth	243 mm
Package width	190 mm
Package height	110 mm
Package weight	1200 g
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Security algorithms	WPA, WPA2
Cables included	AC, LAN (RJ-45)

Weight and Dimensions

Depth	140 mm
Width	150 mm
Height	30 mm
