Devolo Magic 1 User Manual

Appendix 50
devolo Magic 1 WiFi
2-1
5 Appendix
5.1 Technical specifications
5.2 Bandwidth optimization
To significantly improve the transmission capacity
of the network, we recommend that you comply
with the following "connection rules":
b Plug the devolo Magic 1 WiFi
2-1
directly into a
wall socket. Avoid using power strips. This may
impair the transmission of the PLC signals.
b If there are several sockets in the wall directly
next to each other, they behave like a power
strip. Individual sockets are optimal.
Security 128 Bit AES
Device port 2x RJ45
Power consumption Maximum: 7.0 W
Typical: 5.1 W
Stand-by: 2.0 W
Power supply internal
196-250 V AC
50 Hz
Temperature
(Storage/Opera-
ting)
-25°C to 70 °C / 0°C to
40°C
Dimensions
(in mm, without
plug)
152x76x40 (HxWxD)
Ambient conditions 10-90% Humidity,
non-condensing
Certifications CE
Fig. 5: Bandwidth optimization

Devolo Magic 1 Specifications

General

Frequency Band	2.4 GHz
Powerline Networking	Yes
Encryption	128-bit AES
Ethernet LAN data rates	10, 100 Mbit/s
Wi-Fi standards	802.11n
Security algorithms	WPA2
Maximum Data Rate	300 Mbps
Ports	Ethernet
Maximum Powerline Data Rate	1200 Mbit/s
