Procedure
1. Make sure the dryer is not in a dry cycle. The 4-digit numeric display on the dryer controller will show
“LOAd” when the dryer is not in a dry cycle.
2. Press and release the UP or DOWN arrow keys on the dryer controller touch pad to chose the dry
cycle that you want to change (dry cycle 1 through 5). The dry cycle L.E.D. will illuminate to indicate
which dry cycle you are choosing. If you press either arrow key and hold it down, the controller will
sequence through the ve dry cycles.
3. Press and release the CYCLE key on the dryer controller touch pad once you have chosen the dry
cycle you want to change. After you press this key, the programming L.E.D. and the dry time L.E.D.
will illuminate. The dry cycle L.E.D. will remain illuminated. The total dry time will also be displayed on
the 4-digit numeric display.
4. Press and release the UP or DOWN arrow keys to change the total cycle time. Once either of the ar-
row keys is pressed, the dry time L.E.D. and the total dry time on the 4-digit numeric display will ash.
If you press and hold either arrow key down, you will increment (UP arrow) or decrement (DOWN ar-
row) through the total dry times available (1 through 60 minutes). This displayed dry time includes the
cool down time along with the heated time. To not change the total dry time, do not press the arrow
keys to change the total dry time.
5. Press and release the SELECT/ENTER key. Once this key is pressed and released, the dry time L.E.D.
will switch o, the dry cycle L.E.D. and programming L.E.D. will remain on, and the temperature L.E.D.
will illuminate. The drying temperature will also be shown on the 4-digit numeric display.
6. Press and release the UP or DOWN arrow keys to change the drying temperature. Each press and re-
lease of the arrow keys will either increase or decrease the temperature by ve degrees Fahrenheit or
three degrees Celsius, depending on how your dryer controller is set up. Once either of the arrow keys
is pressed, the temperature L.E.D. and the drying temperature on the 4-digit numeric display will ash.
If you press and hold either arrow key down, you will increment (UP arrow) or decrement (DOWN
arrow) your way through the available drying temperatures (10So Fahrenheit or 40° Celsius, up to
19So Fahrenheit or 9( Celsius). If you do not want to change the drying temperature, do not press the
arrow keys. Go to the next step.
7. Press and release the SELECT/ENTER key. Once this key is pressed and released, the temperature
L.E.D. will switch o, the dry cycle L.E.D. and programming L.E.D. will remain on, and the cool down
L.E.D. will illuminate. The cool down time will also be shown on the 4-digit numeric display. 8) Press
and release the UP or DOWN arrow keys to change the cool down time. Once either of the arrow keys
is pressed, the cool down L.E.D. and the cool down time on the 4-digit numeric display will ash. If
you press and hold either arrow key down, you will increment (UP arrow) or decrement (DOWN arrow)
through the cool down times available (2 through 60 minutes). To not change the cool down time, do
not press the arrow keys. Go to the next step.
8. Press and release the SELECT/ENTER key. Once this key is pressed and released, the cool down L.E.D.
and the programming L.E.D. will switch o, and the dry cycle L.E.D. will remain on. The ashing cool
down time on the 4-digit display will stop ashing and remain.
9. At this point, you have two choices. 1) You can perform the modied dry cycle by pressing and re-
leasing the START key on the dryer controller touch pad, or 2) You can clear the modied dry cycle
program by pressing and releasing the STOP key once. If you start the modied cycle, the total dry
time will appear on the 4-digit numeric display and it will count down to 0 as the dry cycle progresses.
If you choose to clear the modied dry cycle, the 4-digit numeric display will change to “LOAd”.
Temporary Dryer Controller Programming Example
Requirements: Dry a load with 40 minutes of actual heat at 18SoF and ve minutes of cool down.
The following procedure will show you how to temporarily modifY the existing dry cycle 1 program for
one cycle of drying. It is based on the assumption that the factory defaults have not been permanently
changed. If they have been changed, the steps of this procedure will be the same, but the values that
are displayed will be dierent. The amount of times that the dryer controller touch pad UP or DOWN keys
must be pressed and released may also be dierent.
If you want the change to be permanent, go to the “Permanent Dryer Controller Programming” section of
this manual.
Procedure
1. After the load has been placed in the dryer, press and release the UP or DOWN touch pad key on the
dryer controller until the L.E.D. for dry cycle 1 is illuminated.
2. Press and release the CYCLE key on the dryer controller touch pad. You will see the number “35” on
the dryer controller display. The programming L.E.D. and dry time L.E.D. will be illuminated.
3. Press and release the UP arrow key on the dryer controller touch pad 10 times so the display will
show a ashing “45”. When the UP arrow touch pad key is pressed the rst time, the number “36” will
be ashing on the dryer controller display. Each number after that will also ash.
4. Now, press and release the SELECT/ENTER touch pad key on the dryer controller. The number “45”
will stop ashing and the dry time L.E.D. will switch o. The dryer controller display will now show
“180”, the temperature L.E.D. will illuminate, and the programming L.E.D. and dry cycle 1 L.E.D. will
remain on.
5. Press and release the UP arrow key on the dryer controller touch pad one time so the controller dis-
play will show a ashing” 185”. Each press of the UP arrow key will increment the temperature by ve
degrees.
6. Now, press and release the SELECT/ENTER touch pad key on the dryer controller. The number “185”
will stop ashing and the temperature L.E.D. will switch o. The dryer control display will now show
a number “5”, the cool down L.E.D. will illuminate, and the programming L.E.D. and dry cycle 1 L.E.D.
will remain on.
7. Press and release the SELECT/ENTER key on the dryer controller touch pad, since the desired cool
down time is ve minutes. After you press the SELECT/ENTER touch pad key on the controller, the
cool down L.E.D. and programming L.E.D. will switch o. The controller display will remain at “5” and
the cycle 1 L.E.D. will remain on.
You are now ready to start the new dry cycle. This new dry cycle will be in eect for one dry cycle only.
After the dry cycle is done, or if the STOP touch pad key on the dryer controller is pressed and released
twice, consecutively, the cycle 1 program will revert to the factory default settings.
If you press the START touch pad key on the dryer controller, the controller display will change from the
number “5” to the number “45” and dry cycle 1 will begin.
