Dexter Laundry DN20X2 - Section 1: Specifications; Express Stack Dryer Specifications

Express Stack Dryer Specications
Model DN20X2ND-15
Capacity:
Dry Weight Capacity - lb (kg) 2 x 20 (2 x 9.1)
Cylinder Volume (per tumbler) - cu ft (L) 7 (198.2)
Speed:
Tumbler Speed - RPM 51
Motor Size (per tumbler) - hp (kW) 0.3 (0.25)
Airow (per tumbler):
60 Hz Model - cfm (M3/min) 370 (10.5)
50 Hz Model - cfm (M3/min) 300 (8.5)
Dimensions:
Cabinet Height - in (cm) 68 1/2 (174)
Cabinet Width - in (cm) 27 (68.6)
Cabinet Depth - in (cm) 44 5/8 (113.3)
Door Opening - in (cm) 18 1/8 (46)
Floor to Lower Door Bottom - in (cm) 8 1/2 (21.6)
Floor to Upper Door Bottom - in (cm) 42 (106.7)
Cylinder Diameter - in (cm) 25 1/2 (64.8)
Cylinder Depth - in (cm) 24 (61)
Lint Screen Area (per tumbler) - sq in (sq cm) 285 (1839)
Weight:
Net Weight - lb (kg) 615 (279)
Shipping Information:
Shipping Weight - lb (kg) 650 (295)
Shipping Height - in (cm) 74 (188)
Shipping Width - in (cm) 31.5 (80)
Shipping Depth - in (cm) 49 (124.5)
Gas Requirements (Gas Models Only):
Gas Supply Connection - in (mm) 1/2 (12.7)
Natural Gas Supply (Water Column) - in (cm) 5-8 (12.7 - 20.3)
LP Gas Supply (Water Column) - in (cm) 11 1/2-14 (29.2-35.6)
Gas Usage (Gas Models Only):
60Hz Model (per tumbler) - BTU/hr (kW) 56,000 (16.4)
50Hz Model (per tumbler) - BTU/hr (kW) 47,000 (13.8)
15
Part # 8533-108-001 10/22
14
Part # 8533-108-001 10/22
