Dexter Laundry DN20X2 - Table of Contents

Dry only fabrics washed in water
to avoid the risk of fire, including
spontaneous combustions, do not dry:
• Items containing foam rubber, or any
similarly textured rubber-like materials.
• Any items on which you have used a
cleaning solvent or which contain amm.
able liquids or solids, such as naptha,
gasoline, or other oils or waxes.
Table of Contents
Section 1:
Specications .............................. 14-15
Installation Dimensions .....................16
Section 2:
Installation and Operation
Installation Clearances ......................20
Make Up Air .....................................21
Electrical Requirements .....................21
Gas Requirements ............................21
Burner Set Up ..................................21
Exhaust Installation ..................... 22-23
Description of Control .................. 24-25
Operating Instructions ................. 27-28
Programming .............................. 28-33
Section 3:
Wiring Schematics
Dryer Idle ........................................36
Motor Starting and Running ...............36
Heat Circuit ......................................36
Over Temperature Thermostat ...........37
Cool Down .......................................37
End of Cycle ..................................... 37
Wiring Diagram for DN20X2 Dryer ......40
Wiring Schematic for DN20X2 Dryer ...41
Section 4:
Service Procedures
Clothes Door Removal .......................44
Clothes Door Latch Adjustment ..........44
Door Switch Removal and Installation .44
Installation of Clothes Door Window and
Gasket .......................................... 44
Dexter Safety Guidelines
WARNING
For your safety, the information in this manual
must be followed to minimize the risk of re
or explosion or to prevent property damage,
personal injury or loss of life.
IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch: do not use any
telephone in your building.
• Clear the room, building or area of all occupants.
• Imm.ediately call your gas supplier from a
neighbor’s telephone.
• Follow the gas supplier’s instructions.
• If you cannot reach your gas supplier, call the
re department. Installation and service must be
performed by a qualied installer, service agency or
the gas supplier.
To activate your warranty, be sure to return
your red warranty form to the factory. Please
have serial number and model ready when
calling for assistance.
10 11
Part # 8533-108-001 10/22 Part # 8533-108-001 10/22
10
Notes
Parts
Data
50Hz
Parts
Maintenance
Electric Heated
Parts Data
Machine
Specs.
Installation
& Operation
Trouble-
shooting
Machine
Service
Electrical
Wiring
