Electrical Requirements:
Gas Models (per stack dryer):
Model Volts / Hz / Phase / Wiring Circuit Breaker Amps / Running Amps / Wire Size
-15 208-240 / 60 / 1 / 2 wire + ground 15 / 3.8 / #12
-15 120 / 60 / 1 / 2 wire + ground 15 / 7.8 / #12
-39 230 / 50 / 1 / 2 wire + ground 15 / 3.8 / 3.5 mm2
-59 230 / 50 / 1 / 2 wire + ground 15 / 3.8 / 3.5 mm2
Electric Models (per tumbler):
Model kW / Volts / Hz / Phase / Wiring Circuit Breaker Amps / Running Amps / Wire Size
-82 15 / 400 / 50 / 3 / 4 wire + ground 30 / 30 / 8.4 mm2
-84 15 / 208 / 60 / 3 / 4 wire + ground 60 / 55 / #4
-85 15 / 240 / 60 / 3 / 4 wire + ground 50 / 50 / #4
Installation Recommendations:
Minimum Clearance Between Machines - in (cm) 0 (0)
Minimum Clearance Behind Machines - in (cm) 18 (45.7)
Make-Up Air Required (per stack dryer) - sq ft (sq cm) 1 (929)
Exhaust Size - in (cm) 8 (20.3)
Max. Exhaust Back Pressure (Water Column) - in (mm) 0.3 (7.6)
Recommended Exhaust Length - ft (m) & 2 elbows 14 (4.3)
16 17
Part # 8533-108-001 10/22 Part # 8533-108-001 10/22
