Dexter Laundry DN20X2 - DN20 X2-85 Part List

Key Description T-20X2 QTY
Wire-BLK, 26” 8220-078-024 2
Wire-BLK, 8” 8220-057-014 6
Wire-WHT, 5.5”, 18 AWG 8220-057-021 2
Wire-BLK, 9.5”, 10 AWG 8220-057-023 12
Wire-BLK, 36”, 12 AWG 8220-057-031 1
Wire-RED, 36”, 12 AWG 8220-057-032 1
Wire-BLK, 17”, 10 AWG 8220-061-011 12
Wire-WHT/BLK, 65”, 18 AWG 8220-063-020 1
Wire-BLK, 22”, 18 AWG 8220-078-014 2
Wire-BRN, 54”, 18 AWG 8220-095-023 2
Wire-RED, 19”, 18 AWG 8220-103-002 2
Wrapper-Housing, Heater 9636-217-001 2
Screw-10B x 1/4 9545-008-001 6
Side-Housing, Heater, Right Hand 9551-063-001 2
Side-Housing, Heater, Left Hand 9551-064-001 2
Side Control Heater 9551-040-001 4
Deector-Bottom Housing 9114-052-001 2
Screw-10AB x 3/8 9545-008-024 6
Bottom-Housing, Heater 9058-029-001 2
Screw-10AB x 3/8 9545-008-024 22
Deector-Wrapper, Housing 9114-053-001 2
Screw-10AB x 3/8 9545-008-024 8
Bae-Housing, Heater 9049-116-001 2
Wrapper-Control, Heater 9636-218-001 2
Cover-Plate, Heater 9074-376-001 2
Side-Control, Heater 9551-040-001 4
Screw-10AB x 3/8 9545-008-024 16
Cover-Control, Heater 9074-375-001 2
Thermostat-Overtemp, Manual Reset 9576-207-006 2
Rail-Din, 35 x 15mm 9488-011-002 2
Relay 5192-285-004 2
Relay, Heatings Element 5192-294-001 2
Varister-Coil Supressor 9377-003-001 2
Circuit Breaker, 2-Pole 5198-214-002 4
Terminal-Lug, Solderless 8652-134-002 4
Heater Element, 8KW 208V 9870-093-004 6
Jumper-Straight 9295-005-002 8
DN20X2 -86
Key Description T-20X2 QTY
Block-Power, 3-Pole 9897-037-001 2
Block-Power, 1-Pole 9897-038-001 2
Wiring-Diagram/Schematic 9506-860-001 1
Booklet-Owners 8514-265-001 1
DN20X2 -86
92 93
