DFI HU101 - Page 46

46
Chapter 3 BIOS Setup
Chapter 3
PCH-IO Configuration
This section illustrates the PCH parameters.
Wake on LAN
Enables or disables the integrated LAN controller to wake the system. (The Wake on
LAN cannot be disabled if ME is set to On at the Sx state.)
PCI Express Confi guration
settings.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
Intel PCH RC Version
Intel PCH SKU Name
Intel PCH Rev ID

PCI Express Confi guration

USB Confi guration
Wake on LAN
1.7.0.0
Premium SKU
04/B2
[Enabled]
Chipset
 Select Screen
 Select Item
Enter: Select
+/
-:
Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
PCI Express Configuration
This field is used to configure the PCI Express settings.
PCI Express Root Port
PCI Express Root Port
Settings.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
PCI Express Confi guration

PCI Express Root Port
Chipset
 Select Screen
 Select Item
Enter: Select
+/
-:
Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Control the PCI Express
Root port.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
PCI Express Root Port 5
ASPM Support
PME SCI
Hot Plug
PCIe Speed
Chipset
 Select Screen
 Select Item
Enter: Select
+/
-:
Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
[Enabled]
[Disabled]
[Enabled]
[Disabled]
[Auto]
