Rear Panel I/O
Ports
• 2 HDMI ports
• 2 RJ45 LAN ports
• 2 USB 2.0 ports
• 2 USB 3.0 ports
• Line-out and mic-in jacks
I/O Connectors
• 3 connectors for 6 external USB 2.0 ports
• 1 connector for 2 external USB 3.0 ports
• 1 vertical USB 2.0/1.1 port* (optional)
• 4 connectors for 4 external serial ports (2.0mm pitch)
- 2 RS232/422/485 (RS232 and/or power)
- 2 RS232
• 1 LVDS LCD panel connector
• 1 LCD/inverter power connector
• 1 eDP connector* (optional)
• 1 8-bit DIO connector
• 1 DIO power connector
• 4-pin 12V power connector
• 1 front audio connector for line-out and mic-in jacks
• 1 S/PDIF connector
• 1 PS/2 connector for keyboard/mouse port
• 1 LPC connector
• 1 SMBus connector
• 3 Serial ATA connectors
• 3 Serial ATA power connectors
• 1 front panel connector
• 1 chassis intrusion connector
• 3 fan connectors
BIOS
• AMI BIOS
- 64Mbit SPI BIOS
Energy Effi cient
Design
• Supports ErP Lot6 power saving* (optional)
• Supports ACPI
• System Power Management
• Wake-On-Events include:
- Wake-On-PS/2 KB/Mouse* (optional)
- Wake-On-USB KB/Mouse* (optional)
- Wake-On-LAN
- RTC timer to power-on the system
• AC power failure recovery
Damage Free
Intelligence
• Monitors CPU/system temperature and overheat alarm
• Monitors VCORE/12V/5V/DDR voltages and failure alarm
• Monitors CPU/system fan speed and failure alarm
• Read back capability that displays temperature, voltage and fan speed
Power
Consumption
• HU101-N4650U: 35.42W with i7-4650U at 1.7GHz and 2x 2GB DDR3L
SODIMM
Temperature
• Operating: 0
o
C to 60
o
C
• Storage: -20
o
C to 85
o
C
Chapter 1 - Introduction
Specifications
Processor
• 4th generation Intel
®
Core
TM
processors
: Intel
®
Core
TM
i7-4650U, 4M Cache,
1.7GHz (3.3GHz)
, 15W
: Intel
®
Core
TM
i5-4300U, 3M Cache,
1.9GHz (2.9GHz)
, 15W
• BGA 1168 packaging technology
• 22nm process technology
Super I/O
Address
• NCT6106/4Eh
System Memory
• Two 204-pin SODIMM sockets
• Supports DDR3L 1333/1600MHz
• Supports up to 16GB system memory
• Supports dual channel memory interface
• DRAM device technologies: 1Gb, 2Gb and 4Gb DDR3L DRAM technologies are
supported for x8 and x16 devices, unbuffered, non-ECC
Expansion
Interfaces
• 1 PCIe x1 slot
• 1 Mini PCIe slot
- Supports USB and PCIe signals
- Supports mSATA
- Supports full size Mini PCIe card
Graphics
• Intel
®
HD Graphics GT series
• Display ports: 2 HDMI, 1 LVDS (default) or 1 eDP* (optional)
• HDMI: resolution up to 4096x2304 @24Hz or 2560x1600 @60Hz
• LVDS: NXP PTN3460, 24-bit, dual channel, resolution up to 1920x1200 @60Hz
• eDP: resolution up to 3200x2000 @60Hz
• Intel
®
Clear Video Technology
• Intel
®
Advanced Vector Extensions 2.0 (Intel
®
AVX 2.0) Instructions
• Supports DirectX 11.1, OpenGL 4.0, OpenCL 1.2
Audio
• Realtek ALC888 5.1-channel High Defi nition Audio
• S/PDIF audio interface
LAN
• Intel
®
I210 PCI Express Gigabit Ethernet controller
• Intel
®
I218 with iAMT9.5 Gigabit Ethernet Phy
• Integrated 10/100/1000 transceiver
• Fully compliant with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Serial ATA
• 3 SATA 3.0 ports with data transfer rate up to 6Gb/s
- SATA port 0 provides adequate space for SATA DOM
• Integrated Advanced Host Controller Interface (AHCI) controller
• Supports RAID 0/1/5
• Supports Intel
®
Smart Response Technology
Active
Management
Technology - AMT
• Supports iAMT9.5
• Out-of-band system access
• Remote troubleshooting and recovery
• Hardware-based agent presence checking
• Proactive alerting
• Remote hardware and software asset tracking
Trusted
Platform
Module - TPM*
(optional)
• Provides a Trusted PC for secure transactions
• Provides software license protection, enforcement and password protection
WatchDog Timer
• Watchdog timeout programmable via software from 1 to 255 seconds
