System Agent (SA) Configuration
This section is used to configure the parameters of System Agent.
Check to enable VT-d
function on MCH.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
System Agent Bridge Name
System Agent RC Version
VT-d Capability
VT-d

Graphics Confi guration

Memory Confi guration
Haswell
1.7.0.0
Supported
[Enabled]
Chipset
VT-d
Enables the VT-d function on MCH.


Enter:
+/
-:
F1:
F2:
F3:
F4:
ESC:
Select Screen
Select Item
Select
Change Opt.
General Help
Previous Values
Optimized Defaults
Save & Exit
Exit
Primary Display
Auto When the system boots, it will auto detects the display device.
IGFX When the system boots, it will first initialize the onboard VGA.
PCIE When the system boots, it will first initialize the PCI Express x1 graphics card.
Internal Graphics
Keeps IGD enabled based on the setup options
.
Graphics Configuration
This field configures the graphics settings.
Select which of IGFX/
PEG/PCI Graphics device
should be Primary Display
or Select SG for switch-
able Gfx.
