Supported Software
Add DMI
1. Use the ← or → arrow keys to select the Add DMI menu.
2. Highlight the item on the left screen that you would like to add
by using the ↑ or ↓ arrow keys, then press <Enter>.
3. The cursor will move to the screen you select allowing you to enter
information about the added item.
4. Press <F10> to save information into the flash ROM.
To view information about the added items, go to the Edit DMI menu.
Load DMI File
1. Use the ← or → arrow keys to select the Load DMI File menu.
2. The following message will appear.
Press [Enter] to select DMI file for load
Press <Enter>.
3. The DMI files will appear on the screen. Select the file you would
like to load and press <Enter>.
4. The following message will appear.
Do you want to execute? (Y/N)
Type <Y>. All previous DMI structures will be destroyed and the
new file will be saved into the flash ROM.
Save DMI File
1. Use the ← or → arrow keys to select the Save DMI File menu.
2. The following message will appear.
Press [Enter] to select DMI file for save
Press <Enter>.
3. Enter the directory and filename under which you would like the
DMI file saved.

DFI PS35-BC Specifications

General

Form Factor	Micro ATX
Socket Type	LGA 775
FSB	1333/1066/800 MHz
Max Memory Support	8GB
Storage Interface	4 x SATA 3Gb/s, 1 x IDE
USB Ports	8 x USB 2.0 (4 rear, 4 via headers)
LAN Speed	10/100/1000 Mbps
Power Connector	24-Pin ATX, 4-Pin ATX 12V
Supported CPU	Intel Core 2 Quad, Core 2 Duo, Pentium Dual-Core, Celeron
Expansion Slots	1 x PCIe x16, 1 x PCIe x1, 2 x PCI
PS/2	2 (Keyboard/Mouse)
