1-3
1.3 Elevator Controls and Trim-System:
1.3.1 Elevator Controls
Elevator system activated via pushrods. Automatic coupling during
assembly of horizontal tail unit.
100% mass balance in vertical tail fin pushrod.
1.3.2 Trim Controls
Trim handle at left hand cockpit wall behind landing gear handle-
