Maintenance Manual LS4
Issued: May 2011
Copyright DG Flugzeugbau GmbH - any copy or publishing prohibited
Manual valid with the up-to-date cover page only
1-12
Parts list landing gears
No.
Description
LS4
LS4-a and
LS4 TN4013
LS4-b
1
front fork
1R2-1
2
left strut
1R2-24
4R2-2e
3
right strut
1R2-2
4R2-62a
4
rear fork
1R2-3
1R2-3e
5
small rubber mounts
2 x 31500 SM 550
6
large rubber mounts
2 x 31700
SM 650
3 x 31700 SM 650
7
swinging arm
1R2-4
3R2-64e
8
drive lever
3 x 4R2-6
9
inner drive
1R2-5a
10
outer drive (drilled
together with inner drive)
4R2-15
4R2-120
11
cockpit handle unit
12
shock absorber
x
13
gas strut 400 N
x
14
bracket for rubber mount
/
3R2-67
15
spring unit support
/
2 x 3R2-66b
16
upper adjustment screw
4R2-17
4R2-119a
17
lower adjustment screw
4R2-8
4R2-124a
1.14 Wheel Brake
Feet operated; activated by Bowden cable from rudder pedals.
