5.5 Limit values for control surface deflections in mm/in. ,only LS4-b
Elevator
local radius
mm/in
down *
23°to 19°
up *
24°to 30°
145 mm
241 to 251 mm
352 to 363 mm
5.709 in.
9.488 to 9.882 in.
13.858 to 14.291 in.
146 mm
241 to 251 mm
352 to 364 mm
5.748 in.
9.499 to 9.882 in.
13.858 to 14.331 in.
147 mm
241 to 251 mm
353 to 365 mm
5.787 in.
9.488 to 9.882 in.
13.898to 14.370 in.
148 mm
241 to 251 mm
353 to 365 mm
5.827 in.
9.488 to 9.882 in.
13.898 to 14.370 in.
149 mm
241 to 251 mm
354 to 366 mm
5.8665 in.
9,488 to 9.882 in.
13.937 to 14.409 in.
150 mm
241 to 251 mm
355 to 367 mm
5,906 in.
9.488 to 9.882 in.
13.976 to 14.449 in.
151 mm
241 to 251 mm
355 to 367 mm
5.945 in.
9.488 to 9,882 in.
13.976 to 14.449 in.
152 mm
241 to 251 mm
356 to 368 mm
5.984 in.
9.488 to 9.882 in.
14.016 to 14,488 in.
153 mm
241 to 251 mm
357 to 369 mm
6.024 in.
9.488 to 9.882 in.
14.055 to 14.528 in.
154 mm
241 to 252 mm
357 to 369 mm
6.063 in.
9.488 to 9.921 in.
14.055 to 14.528 in.
155 mm
241 to 252 mm
358 to 370 mm
6.102 in.
9.488 to 9.921 in.
14.094 to 14.567 in.
* measured up to reference point see section 5.1.
