DG Flugzeugbau LS4 - Pressure Ports; Pressure Ports LS4, LS4-A; Pressure Ports LS4-B

Maintenance Manual LS4
Issued: May 2011
Copyright DG Flugzeugbau GmbH - any copy or publishing prohibited
Manual valid with the up-to-date cover page only
1-14
1.16 Pressure ports
1.16.1 Pressure ports LS4, LS4-a:
1.16.2 Pressure ports LS4-b:
,
forward static pressure
total pressure
rear static pressure
TE-Port
TE-Port
Pitot pressure
if nose hook is installed
for ASI and altimeter only
