DG Flugzeugbau LS4 - Altimeter; Seat Belt Harness (with Multiple Point Buckles); Compass

Maintenance Manual LS4
Issued: May 2011
Copyright DG Flugzeugbau GmbH - any copy or publishing prohibited
Manual valid with the up-to-date cover page only
9-2
9.2 Altimeter
Manufacturer
Type
TCDS No.
Winter
4 FGH 10 (Diameter 80mm)
1000-10000m Ident.No.. 4100
3000-30000ft Ident.No.. 4330
TS 10.220/46
Winter
4 FGH 20 (Diameter 58mm)
1000-10000m Ident.No. 4220
TS 10.220/47
Winter
4 FGH 40 (Diameter 58mm)
1000-20000ft Ident.No.. 4550
TS 10.220/48
PZL
W-12S in m
or other Altimeters approved according to TSO, JTSO or ETSO for use in
aircraft; one turn of dial max. 1000 m or 3000 ft. A similar FAA approved
altimeter to meet TSO C10 with a range of approximately 30000 ft and a
mercury or millibar or hektopascal subscale may be used.
When an altimeter of up to 20000 ft only is being used, a placard must be
near the altimeter stating: Maximum flying altitude 20000 ft. See also
Flight Manual section 2-8.
9.3 Seat Belt Harness (with multiple point buckles)
Manufacturer
Type
TCDS No.
Schroth
4-01-0104(Lap belt and
shoulder strap)
40.073/11
Gadringer
BAGU 4502
mit SCHUGU 2300
40.070/32 no central
40.071/05 buckle
Gadringer
BAGU 5402 oder BAGU 5302
with SCHUGU 2700
40.070/32
40.071/05
Autoflug
BAGU FAG-7 D
SCHUGU FAG-7 H
40.070/30
40.071/21
9.4 Compass
Manufacturer
Type
TCDS No.
Ludolph
FK 16, FK 5, FK 10
10.410/3
Airpath
C 2300
TS 10.220/47
Airpath
C 2400 P
PZL
BS1, KJ-13A
FD 19/77
Bohli
46 MFK 1
Not approved, only as
additional system
