273 562 -732 562 -751 562 -770 562 -790 -810 -831 -853
274 561 -731 561 -750 561 -769 561 -789 -808 -829 -851
275 559 -730 559 -748 559 -768 559 -787 -807 -828 -850
276 558 -729 558 -747 558 -766 558 -786 -805 -826 -848
277 557 -728 557 -746 557 -765 557 -784 -804 -825 -846
278 556 -726 556 -745 556 -764 556 -783 -803 -823 -845
279 555 -725 555 -743 555 -762 555 -782 -801 -822 -843
280 553 -724 553 -742 553 -761 553 -780 -800 -820 -842
281 552 -723 552 -741 552 -760 552 -779 -798 -819 -840
282 551 -722 551 -740 551 -759 551 -778 -797 -817 -838
283 550 -721 550 -739 550 -757 550 -776 -795 -816 -837
284 549 -719 549 -737 549 -756 549 -775 -794 -814 -835
285 548 -718 548 -736 548 -755 548 -774 -793 -813 -834
286 547 -717 547 -735 547 -754 547 -772 -791 -811 -832
287 545 -716 545 -734 545 -752 545 -771 -790 -810 -831
288 544 -715 544 -733 544 -751 544 -770 -789 -808 -829
289 543 -714 543 -731 543 -750 543 -768 -787 -807 -828
290 542 -713 542 -730 542 -749 542 -767 -786 -806 -826
291 541 -712 541 -729 541 -747 541 -766 -785 -804 -825
292 540 -711 540 -728 540 -746 540 -765 -783 -803 -823
293 539 -710 539 -727 539 -745 539 -763 -782 -801 -822
294 538 -709 538 -726 538 -744 538 -762 -781 -800 -820
295 537 -708 537 -725 537 -743 537 -761 -779 -799 -819
296 536 -707 536 -724 536 -742 536 -760 -778 -797 -818
297 535 -705 535 -723 535 -740 535 -759 -777 -796 -816
298 534 -704 534 -721 534 -739 534 -757 -775 -795 -815
299 533 -703 533 -720 533 -738 533 -756 -774 -793 -813
300 532 -702 532 -719 532 -737 532 -755 -773 -792 -812
301 531 -701 531 -718 531 -736 531 -754 -772 -791 -811
302 530 -700 530 -717 530 -735 530 -753 -771 -789 -809
303 528 -699 528 -716 528 -734 528 -751 -769 -788 -808
304 528 -698 528 -715 528 -733 528 -750 -768 -787 -807
305 527 -697 527 -714 527 -732 527 -749 -767 -786 -805
306 526 -696 526 -713 526 -730 526 -748 -766 -784 -804
307 525 -696 525 -712 525 -729 525 -747 -764 -783 -803
308 524 -695 524 -711 524 -728 524 -746 -763 -782 -801
309 523 -694 523 -710 523 -727 523 -745 -762 -781 -800
310 522 -693 522 -709 522 -726 522 -743 -761 -779 -799
Empty mass C.G. range tables cont
(empty mass from 273 kg on, cockpit load 95 – 110 kg) Table for <kg> and <mm>
Empty
mass
<kg>
Cockpit load <kg> / Empty mass C.G. range <mm>
max. + min. cockpit load
min. cockpit load
110-95
110-100
110-105
110-110
- 115
- 120
-125
