Maintenance Manual LS4
Issued: May 2011
Copyright DG Flugzeugbau GmbH - any copy or publishing prohibited
Manual valid with the up-to-date cover page only
5-6
Limit values for control surface deflections in mm/in. ,only LS4-b cont.
Aileron
local radius
mm/in
Down
13° to 15°
Up
21° up to 25°
155 mm
35 to 40 mm
56 to 67 mm
6.102 in.
1.378 to 1.575 in.
2.205 to 2.6381 in.
156 mm
35 to 41 mm
57 to 68 mm
6.142 in.
1.378 to 1.614 in.
2.244 to 2.6771 in.
157 mm
36 to 41 mm
57 to 68 mm
6.181 in.
1.417 to 1.614 in.
2.244 to 2.6771 in.
158 mm
36 to 41 mm
58 to 68 mm
6.221 in.
1.417 to 1.614 in.
2.284 to 2.677 in.
159 mm
36 to 42 mm
58 to 69 mm
6.260 in.
1.417 to 1.654 in.
2.284 to 2.717 in.
160 mm
36 to 42 mm
58 to 69 mm
6.299 in.
1.417 to 1.654 in.
2.284 to 2.717 in.
161 mm
36 to 42 mm
59 to 70 mm
6.339 in.
1.417 to 1.654 in.
2.323 to 2.756 in.
162 mm
37 to 42 mm
59 to 70 mm
6.378 in.
1.457 to 1.654 in-
2.323 to 2.756 in.
163 mm
37 to 43 mm
59 to 71 mm
6.417 in.
1.457 to 1.693 in.
2.323 to 2.795 in.
164 mm
37 to 43 mm
60 to 71 mm
6.457 in.
1.457 to 1.693
2.362 to 2.7951 in.
165 mm
37 to 43 mm
60 to 71 mm
6.496 in.
1.457 to 1.693 in.
2.362 to 2.795 in.
