Attach the dust collector
This section describes how to install dust collectors with interlocked functions on the machine. If you are using a dust collector
that does not have an interlock function, connect the dust collector to the dust collector according to your dust collector's
instruction manual.
Procedure
1.
Connect the dust extractor () to the aircraft using the dust extractor hose.
Use the dust collecting hose supplied with your dust collector. For detailed connection methods, refer to the instruction
manual of your dust collector.
2.
Plug the interlock cable provided with the dust collector into the expansion terminal () of the unit.
