Important
Be sure to check that the power cord is not connected before removing the fixture.
Important
Be careful not to drop screws or fasteners into the aircraft. Doing so can damage the unit or cause it to malfunction.
Important
The torque screwdriver uses a handle and bit. Do not use sleeves.
Remove the fasteners
• To protect the unit from transport vibrations, the unit is fitted with four fasteners. Once the aircraft is installed, remove all
fasteners. Turning on the power while the fixture is attached to the aircraft may cause malfunction or failure.
• Fixtures are required for transport. Keep this manual in a safe place so as not to lose it.
Necessary items
Procedure
1. Open the milling area cover.
2. Remove the four screws with a torque screwdriver to remove fixture A.
Torque
screwdriver
(0.6 N ・ m)
Install the aircraft
