Warning
Be sure to operate the dust collector.
Machining scraps and workpieces may ignite/cause injury to personnel.
Warning
Do not use a vacuum cleaner to vacuum off any machining scraps.
Use of an ordinary vacuum cleaner to breathe fine particles may cause a fire or explosion.
Check before operation
Dust collector
Since this machine cuts materials, machining scraps are produced during machining. A separate dust
collector must be provided. Insert the dust collector hose into the dust collector pipe of the machine and
use it.
Prepare a dust collector that meets the following conditions.
•
Static pressure: 26 kPa or more
•
4
㎥
/min Above
•
Dust collecting hose [A] which fills the inner or
outer diameter of the dust collecting pipe
When a dust collecting hose () is put on the outside
of the dust collecting pipe (): Inner diameter of the
dust collecting hose: 50.8 mm
[B]
When inserting the dust collecting hose () inside
the dust collecting pipe (): Outer diameter of the
dust collecting hose: 45.6 mm
