Nominal Optical Output Power*
* Units manufactured since December 1, 1997. For performance of units
manufactured before December 1, 1997, contact your Philips representative for
specifications. (Refer to the serial number label for date of manufacturer.)
**Reduce these power levels by 0.2 dB per connection between the optical power
meter and the bulkhead. For example, if you use a jumper between the power
meter and the bulkhead, subtract 0.4 dB for loss.
7. Turn off the laser by turning the key counterclockwise.
The LASER LED goes out (dark).
8. Remove the shield and unplug the optical power meter
from the transmitter.
9. Connect the system fiber to the transmitter.
10. Reinstall the shield; be sure to tighten both of its screws.
Proceed to Checking the Laser Bias Current.
Model Nominal Optical Output Power**
210-TX & 210A-TX 6 dBm
212-TX& 212A-TX 8 dBm
214-TX& 214A-TX 10 dBm
705-TX & 805C/E/G-TX 3 dBm
706-TX & 806C/E/G-TX 4 dBm
707-TX & 807C/E/G-TX 5 dBm
709-TX & 809C/E/G-TX 6 dBm
710-TX & 810C/E/G-TX 7 dBm
711-TX & 811C/E/G-TX 8 dBm
712-TX & 812C/E/G-TX 9 dBm
713-TX & 813C/E/G-TX 10 dBm
714-TX & 814C/E/G-TX 11 dBm
715-TX & 815C/E/G-TX 12 dBm
210-QTX 10 dBm
810-QTX 10 dBm
