112 9 November 2001 Transmitters
8. Return the fiber-management tray to its upright position.
Do not twist or pinch the fiber.
Proceed to “Connecting the RF Signal.”
Figure 51. Fiber Routing
One possible fiber-routing method routes all fiber in the same
direction. Fiber may also be routed to both right and left as long
as fibers do not cross over one another.
