10



8. Threadthefour(4)Allenboltandflat
washerassemblies(I‐9&I‐4)throughthe
baseoftheseatbackassembly(J)and
intotheseatslideassembly(H).Tighten
firmlyafterallboltsareengaged.
9. Threadtheseatheightadjusterknob(M‐
2)intotheseatbackmount(M)two
turns.
10. Whilepullingoutwardonthese
atheight
adjusterknob,slidetheseatbackonto
theseatmast(J).Releasetheknobto
engagethesetpin.Ensuretheseatbackis
indexedinoneoftheheightadjustment
holes.Rotatetheknob(M‐2)clockwiseto
locktheposition.
11. Whilesupportingtheseatbase(P),thread
thefour(4)Phillipsscrews(I‐11)though
thefore‐aftseatadjustmentlever(H‐10)
andintothefourthreadedinsertslocated
intheundersideofthese
atbase(P).
Tightenallfour(4)bolts.
12. Turntheseatbase(P)right‐sideupand
alignthemountingholesintheunderside
ofthebasewiththoselocatedintheseat
slideassembly(H).
13. Threadfour(4)Allenboltandflatwasher
assemblies(I‐3&I‐4)throughthese
at
slide(H)andintheseatbase(P).Tighten
allboltsfirmly.
