Diamondback 910Sr - ASSEMBLY INSTRUCTIONS


910SrOwner’sManual

9

ASSEMBLYINSTRUCTIONS



1. Unpackthe910Srfromthecarton.
Pleaserecycle.
2. Verifythecartoncontainsallpartsfrom
thelist.
3. Removetheshortsectionofsteeltubing
fromthefrontstabilizerreceiverby
removingthetwo(2)Allenfixingbolts
withtheenclosedwrench.Discardthis
item.
4. Alignthefrontstabilize
rassembly(K)withthereceivermountedtotheframeand
looselyinstalltwo(2)setsoftheAllenboltsandcurvedwasherassemblies(I‐1&
I‐2)throughtheframeandintothefrontstabilizer(K).
5. Looselyinstalltwo(2)setsoftheAllenboltandflatwasherassemblie
s(I‐1&I‐4)
throughtheundersideoftheframereceiverandintofrontstabilizer(K).
6. Repeatthesestepsfortherearstabilizer(L).Looselyinstalltwo(2)setsofAllen
boltandcurvedwasherassemblies(I‐1&I‐2),followedbythetw
o(2)setsofAllen
boltandflatwasherassemblies(I‐2&I‐5).
7. Tightenalleight(8)Allenbolts(I‐1)firmlywiththeprovidedAllenwrenchtofix
thefrontandrearstabilizers.
