Diamondback 910Sr - Page 11


910SrOwner’sManual

11


14. Identifytheleftandrightpedals.Theendsofthepedalaxlesaremarkedwithan“L”forleftand“R”forright.Installtherightpedal
(C‐13R)intotherightcrankbyhand,rotatingtheaxleinaclockwisedirection.
15. Threadtheleftpedal(C‐13L)intotheleftcrankbyhandinacounter‐clockwisedirection.
16. Usetheenclosedpedalwrenchtofirmlyaffixthepedalstothecranks.Retightenpedalsafterapproximatelyten(10)hoursofuse.
17. Tightentheleft&rightcrankfixingbolts(C‐22)withthe enclosedAllenwrench.Re‐tightenafterapproximatelyten(10)hoursofuse.
18. Aligntherearha
ndlebarassembly(N)withthemountingplateontheseatmast(J).ThreadthefourAllenboltandflatwasher
assemblies(I‐9&I‐4)throughthehandlebarand(N)andintotheholesatthebaseoftheseatmast(J).Whenallboltsareenga
ged,
tightenfirmlywiththeprovideAllenwrench.
19. Plugrearheartrateconnector(H‐23)intothepulsewireinputjack(N‐4).
