20. Removethefive(5)Allenbolts(B‐9),four
(4)flatwashers(B‐8)andone(1)curved
washer(B‐7)fromthemainframeandset
aside.
21. Orientandslidethelowerconsolemast
cover(C‐12)upwardontotheconsolemast
(B)andholdinplace,halfthewayupthe
mast.Whilesup
portingtheconsolemast
(B),carefullyjoinconnectorB‐12withC‐21
andconnectorB‐13withC‐20.Makesure
theconnectionsarecomplete.
22. Slidetheconsolemast(B)intoplaceonto
themainframe(t
akingcaretonotdamage
thecables).Installthetwo(2)Allenboltand
flatwasherassemblies(B‐9&B‐8)through
thelowerholesoneachsideofconsole
mastandintotheframe.Tightenfirmly.
23. Re‐installtheAllenboltandcurvedwasher
assembly(B‐9&B‐7)intothefrontofthe
cons
olemast.Tightenfirmly.
24. Slidetheconsolemastcover(C‐12)
downward,alignwiththesidecaseplastics
andsnapintoplace.
25. Re‐installthefinaltwo(2)Allenboltandflat
washerassemblies(B‐9&B‐8)intoupper
holesoneac
hsideoftheconsolemast.
26. Placethewaterbottle(B‐10)inthewater
bottlecage.
