Battery
Pin Label Description
Red Wire Battery +12V
Black Wire Battery Ground
PM300 Implement
Pin # Description
1 Row 1 (green)
2 Row 2 (brown)
3 Row 3 (blue)
4 Row 4 (orange)
5 Row 5 (yellow)
6 Row 6 (violet)
7 Row 7 (gray)
8 Row 8 (pink)
9 Row 9 (tan)
10 Row 10 (white/black)
11 Row 11 (red/black)
12 Row 12 (green/black)
13 Row 13 (orange/black)
14 Row 14 (blue/black)
15 Row 15 (black/white)
16 Row 16 (red/white)
17-23 No connection
24 8 V sensor power (red)
25 8 V sensor power (red/black/white)
26 Sensor return (black)
27 Sensor return (white/black/red)
28 No connection
29 Hopper 1 (green/white)
30 Hopper 2 (blue/white)
31 Shaft/Fan/Flow (black/red)
32 8 V power (red)
33 12 V switched power (white/red)
34 12 V return (black)
35 RS-232 Rx (blue/red)
36 RS-232 Tx (red/green)
37 Lift switch (orange/red)
Ground Speed
Pin # Description
1 Ground (black)
2 Signal (green)
3 Power (red)
4 Sense (white)
PM332 Implement
Pin # Description
1 Row 1 green)
2 Row 2 (brown)
3 Row 3 (blue)
4 Row 4 (orange)
5 Row 5 (yellow)
6 Row 6 (violet)
7 Row 7 (gray)
8 Row 8 (pink)
9 Row 9 (tan)
10 Row 10 (white/black)
11 Row 11 (red/black)
12 Row 12 (green/black)
13 Row 13 (orange/black)
14 Row 14 (blue/black)
15 Row 15 (black/white)
16 Row 16 (red/white)
17 Row 17 (green/white)
18 Row 18 (blue/white)
19 Row 19 (black/red)
20 Row 20 (white/red)
21 Row 21 (orange/red)
22 Row 22 (blue/red)
23 Row 23 (red/green)
24 +8 V Snsr Pwr Left (red)
25 +8 V Snsr Pwr Right (red/blk/white)
26 Ground Left (black)
27 Ground Right (white/black/red)
28 Row 24 (orange)
29 Row 25 (black/white/red)
30 Row 26 (green/black/white)
31 Row 27 (orange/black/white)
32 Row 28 (blue/black/white)
33 Row 29 (black/red/green)
34 Row 30 (white/red/green)
35 Row 31 (red/black/green)
36 Row 32 (green/black/orange)
37 Lift Switch (white)
