DIG RBC 7000 User Manual

6
If a backflow preventer is part of the faucet (new houses) do not install any other
backflow preventer to the faucet. If backflow preventers are part of your city code
and you have purchased a unit as part of your drip system, install the device on the
downstream side of the RBC 7000 (Figure 6 and 6a).
It is best to include a filter on a drip system. The filter cleans small particles out of
the water that would otherwise clog the drippers. The filters can also automatically
apply fertilizer through a drip system (Figure 7 and 8).
backflow preventer
Hose end drip system installation using a pressure regulator
pressure regulator
swivel adapter
to drip system
Figure 6 Figure 6a
Hose end drip system installation using a filter and a pressure regulator
Figure 8Figure 7
filter
pressure regulator
swivel adapter
to drip system
water
flow
water
flow
backflow preventer
