Digi ConnectCore User Manual

ConnectCore for i.MX51
©2011DigiInternational,Inc. 23
9 GPIO27 DISP1_DAT8 i.MX51: DISP1_DAT8 HDMI, VGA and LCD1 Data, Boot
Configuration
On Development Kit DISP1
and DISP2 are configured at
18-bit, and connected to 24-
bit LCDs.
On Development Kit some
DISP1 signals are used to
configure the boot process.
On Early Availability Kit
DISP1 and DISP2 are
configured at 24-bit, and
connected to 24-bit LCDs.
10 GPIO27 DISP1_DAT9 i.MX51: DISP1_DAT9 HDMI, VGA and LCD1 Data, Boot
Configuration
11 GPIO27 DISP1_DAT10 i.MX51: DISP1_DAT10 HDMI, VGA and LCD1 Data, Boot
Configuration
12 GPIO27 DISP1_DAT11 i.MX51: DISP1_DAT11 HDMI, VGA and LCD1 Data, Boot
Configuration
13 GPIO27 DISP1_DAT12 i.MX51: DISP1_DAT12 HDMI, VGA and LCD1 Data, Boot
Configuration
14 GPIO27 DISP1_DAT13 i.MX51: DISP1_DAT13 HDMI, VGA and LCD1 Data, Boot
Configuration
15 GPIO27 DISP1_DAT14 i.MX51: DISP1_DAT14 HDMI, VGA and LCD1 Data, Boot
Configuration
16 GPIO27 DISP1_DAT15 i.MX51: DISP1_DAT15 HDMI, VGA and LCD1 Data, Boot
Configuration
17 GPIO27 DISP1_DAT16 i.MX51: DISP1_DAT16 HDMI, VGA and LCD1 Data, Boot
Configuration
18 GPIO27 DISP1_DAT17 i.MX51: DISP1_DAT17 HDMI, VGA and LCD1 Data, Boot
Configuration
19 GPIO27 DISP1_DAT18 i.MX51: DISP1_DAT18 Not used
20 GPIO27 DISP1_DAT19 i.MX51: DISP1_DAT19 Not used
21 GPIO27 DISP1_DAT20 i.MX51: DISP1_DAT20 Boot Configuration
22 GPIO27 DISP1_DAT21 i.MX51: DISP1_DAT21 Boot Configuration
23 GPIO27 DISP1_DAT22 i.MX51: DISP1_DAT22 LCD2 Data
24 GPIO27 DISP1_DAT23 i.MX51: DISP1_DAT23 LCD2 Data
25 GPIO27 DI1_PIN2 i.MX51: DI1_PIN2 HDMI, VGA and LCD1 HSYNC
26 - GND - -
27 GPIO27 DI1_PIN11/GPIO3_0 i.MX51: DI1_PIN11 LCD1 PWREN#
28 GPIO27 DI1_DISP_CLK i.MX51: DI1_DISP_CLK HDMI, VGA and LCD1 Clock
29 GPIO27 DI1_PIN13/GPIO3_2 i.MX51: DI1_PIN13 LCD1 and LCD2 GPIO2
30 GPIO27 DI1_PIN3 i.MX51: DI1_PIN3 HDMI, VGA and LCD1 VSYNC
31 GPIO27 DI1_PIN15 i.MX51: DI1_PIN15 HDMI, VGA and LCD1 DRDY
32 GPIO27 DI1_PIN12/GPIO3_1 i.MX51: DI1_PIN12 LCD2 PWREN#
33 GPIO27 DI_GP2 i.MX51: DI_GP2 Not used
34 GPIO27 DI_GP1 i.MX51: DI_GP1 Not used
Pin Type Signal name Use on module Use on development board Comments
