ConnectCore for i.MX51
©2011DigiInternational,Inc. 80
The I
2
C device address of the HDMI transmitter is the following:
HDMI Connector, J19
The development board provides an HDMI connector, J19. THe HDMI interface is connected to
the Display 1 interface of the ConnectCore for i.MX51 CPU.
The table below shows the pinout of the HDMI connector:
Interface I
2
C Address (7 bits)
HDMI transmitter (AD9389)2 0 x 39
Pin Signal
1HDMI_TX2+
2GND
3HDMI_TX2-
4HDMI_TX1+
5GND
6HDMI_TX1-
7HDMI_TX0+
8GND
9HDMI_TX0-
10 HDMI_TXC+
11 GND
12 HDMI_TXC-
13 NC
14 NC
15 HDMI_SCL
16 HDMI_SDA
17 GND
18 +5V
19 HOTPLUG_DET
