ConnectCore for i.MX51
©2011DigiInternational,Inc. 69
The I
2
C device address of the audio CODEC is the following:
Three stereo audio jacks are provided on the development board:
J18 connector for LINE+OUT
J12 connector for LINE+IN
J15 connector for microphone
Line-out Connector Pinout, J18
Line-in Connector Pinout, J12
Microphone Connector Pinou, J15
Interface I
2
C Address (7 bits)
Audio CODEC (WM8753L) 0 x 1A
Pin Signal
1 GND
2 LINE-OUT-RIGHT
3 LINE-OUT-LEFT
4 HEADPHONE-DETECT
5 -
Pin Signal
1 GND
2 LINE-IN-RIGHT
3 LINE-IN-LEFT
4 GND
5 GND
Pin Signal
1 GND
2 MIC-IN
3 MICBIAS
4 GND
5 GND
