API operation API frames
XBee/XBee-PRO ZigBee RF Modules User Guide 134
If the commissioning push button is pressed on a remote router device with 64-bit address 0x0013A200
40522BAA, 16-bit address 0x7D84, and default NI string, the preceding node identification indicator would be
received. 00 03 00 00 appears before the checksum with the DD value only if ATNO and 0x01.
Frame-specific
Data
64-bit Network
address
17 0x00
Indicates the 64-bit address of the remote module that
transmitted the node identification frame
18 0x13
19 0xA2
20 0x00
21 0x40
22 0x52
23 0x2B
24 0xAA
NI String
25 0x20
Node identifier string on the remote device. The NI-String is
terminated with a NULL byte (0x00)
26 0x00
Parent 16-bit
address
27 0xFF
Indicates the 16-bit address of the Remote's parent or
0xFFFE if the remote has no parent
28 0xFE
Device Type
29 0x01
0 = Coordinator
1 = Router
2 = End Device
Source Event
30 0x01
1 = Frame sent by node identification nation pushbutton
event (see the D0 command)
2 = Frame sent after joining event occurred (see the JN
command).
3 = Frame sent after power cycle event occurred (see the JN
command)
Digi Profile ID
31 0xC1
Set to Digi's application profile ID
32 0x05
Manufacturer ID
33 0x10
Set to Digi's Manufacturer ID
34 0x1E
Checksum
35 0x1B
0xFF - the 8 bit sum of bytes from offset 3 to this byte
Frame Fields Offset Example Description
