API operation API frames
XBee/XBee-PRO ZigBee RF Modules User Guide 121
Example: send a data transmission to the coordinator (64-bit address of 0x00s) using a source endpoint of 0xA0,
destination endpoint 0xA1, cluster ID =0x1554, and profile ID 0xC105. Payload will be “TxData”.
Remote AT Command Request
Frame type: 0x17
Used to query or set module parameters on a remote device. For parameter changes on the remote device to
take effect, changes must be applied, either by setting the apply changes options bit, or by sending an AC
command to the remote.
Frame-specific
Data
Data Payload
23 0x54
Data that is sent to the destination device
24 0x78
25 0x44
26 0x61
27 0x74
28 0x61
Checksum
29 0x3A
0xFF - the 8 bit sum of bytes from offset 3 to this byte.
Frame Fields Offset Example Description
Frame Fields Offset Example Description
Start Delimiter
00x7E
Length
MSB 1 0x00
Number of bytes between the length and the checksum
LSB 2 0x10
Frame-specific
Data
Frame Type
30x17
Frame ID
40x01
Identifies the UART data frame for the host to correlate with a
subsequent ACK. If set to 0, no response is sent.
64-bit
Destination
Address
MSB 5 0x00
Set to the 64-bit address of the destination device. The following
addresses are also supported:
0x0000000000000000 - Reserved 64-bit address for the coordinator
0x000000000000FFFF - Broadcast address
60x13
70xA2
80x00
90x40
10 0x40
11 0x11
LSB 12 0x22
