Command reference tables Networking commands
XBee/XBee-PRO ZigBee RF Modules User Guide 160
JV Channel Verification. Set/Read the channel verification
parameter. If JV=1, a router will verify the coordinator is
on its operating channel when joining or coming up
from a power cycle. If a coordinator is not detected, the
router will leave its current channel and attempt to join
a new PAN. If JV=0, the router will continue operating on
its current channel even if a coordinator is not detected.
R0 - Channel verification
disabled
1 - Channel verification
enabled
0
NW Network Watchdog Timeout. Set/read the network
watchdog timeout value. If NW is set > 0, the router will
monitor communication from the coordinator (or data
collector) and leave the network if it cannot
communicate with the coordinator for 3 NW periods.
The timer is reset each time data is received from or sent
to a coordinator, or if a many-to-one broadcast is
received.
R0 - 0x64FF
[x 1 minute]
(up to over 17 days)
0 (disabled)
JN Join Notification. Set / read the join notification
setting. If enabled, the module will transmit a broadcast
node identification packet on power up and when
joining. This action blinks the Associate LED rapidly on
all devices that receive the transmission, and sends an
API frame out the UART of API devices. This feature
should be disabled for large networks to prevent
excessive broadcasts.
RE 0 - 1 0
AR Aggregate Routing Notification. Set/read the periodic
time for broadcasting aggregate route messages. If
used, these messages enable many-to-one routing to
the broadcasting device. Set AR to 0x00 to send only one
broadcast, to 0xFF to disable broadcasts, or to other
values for periodic broadcasts in 10 second units.
CR 0 - 0xFF (x10 seconds) 0xFF
(disabled)
DJ Disable Joining. Setting this register to 1 will disable
the device from joining. This setting is not writable (WR)
and will reset to zero after a power cycle.
RE 1 (enabled) 0 [not
writable]
II Initial ID. This register determines the operating 16-bit
PAN ID for the network. Changing this value will cause
the Coordinator to leave the network and form another.
A setting of 0xFFFF allows the system to choose its own
16 bit 802.15.4 PAN Identifier.
This setting is not writable (WR) and will reset to 0xFFFF
after a power cycle.
C 0x0000-0xFFFF 0xFFFF [not
writable]
1. Node types that support the command: C = Coordinator, R = Router, E = End Device
