C|24 Guide104
Preamps 1–8
Line Out 1–8
Mic In 1–8
Line/DI In 1–8
5
Submixer
In 7 Left
18 6 19
6
Submixer
In 7 Right
4175
7
Submixer
In 8 Left
15 3 16
8
Submixer
In 8 Right
1142
Preamp Line Outputs 1–8
Channel Hot (+) Cold (–) Ground (shield)
1 Preamp
Line Out 1
24 12 25
2 Preamp
Line Out 2
10 23 11
3 Preamp
Line Out 3
21 9 22
4 Preamp
Line Out 4
7208
5 Preamp
Line Out 5
18 6 19
6 Preamp
Line Out 6
4175
7 Preamp
Line Out 7
15 3 16
8 Preamp
Line Out 8
1142
Submixer Stereo Inputs 5–8
Channel Hot (+) Cold (–) Ground (shield)
Mic Preamp Inputs 1–8
Channel Hot (+) Cold (–) Ground (shield)
1 Preamp
Mic In 1
24 12 25
2 Preamp
Mic In 2
10 23 11
3 Preamp
Mic In 3
21 9 22
4 Preamp
Mic In 4
7208
5 Preamp
Mic In 5
18 6 19
6 Preamp
Mic In 6
4175
7 Preamp
Mic In 7
15 3 16
8 Preamp
Mic In 8
1142
Mic Preamp Inputs 1–8
Channel Hot (+) Cold (–) Ground (shield)
1 Preamp
Line In 1
24 12 25
2 Preamp
Line In 2
10 23 11
3 Preamp
Line In 3
21 9 22
4 Preamp
Line In 4
7208
