Appendix A: C|24 Connector Pinouts 107
Ext Stereo In
Ext St 1 + St 2
Cue Outputs
Cues + SLS + TB
Control Room Out
5.1 Mon Out L:1 R:3
External Stereo Inputs 1 and 2
Channel Hot (+) Cold (–)
Ground
(shield)
1 Stereo In
1 Left
24 12 25
1 Stereo In
1 Right
10 23 11
3 Stereo In
2 Left
21 9 22
4 Stereo In
2 Right
7208
5 (unused)
18 6 19
6 (unused)
4175
7 (unused)
15 3 16
8 (unused)
1142
Cue and Studio LS Monitor Outputs
Channel Hot (+) Cold (–)
Ground
(shield)
1 Cue Out
Left
24 12 25
2 Cue Out
Right
10 23 11
3 Studio
LS Out
Left
21 9 22
4 Studio
LS Out
Right
7208
5 Talkback
Slate Out
18 6 19
6 (unused)
4175
7 (unused)
15 3 16
8 (unused)
1142
Main and Alternate Outputs
Channel Hot (+) Cold (–)
Ground
(shield)
1 Main Out Left 24 12 25
2 Main Out
Center
10 23 11
3 Main Out
Right
21 9 22
4 Main Out Left
Surround
7208
5 Main Out
Right Surround
18 6 19
6 Main Out LFE 4 17 5
7 Alt Out Left 15 3 16
8 Alt Out Right 1 14 2
Cue and Studio LS Monitor Outputs
Channel Hot (+) Cold (–)
Ground
(shield)
